| NAVigator |
|
| Network |
|---|
| Network interface controllers (NICs) | 1 NAV
1 OOB |
| Network | Gigabit Ethernet |
| Connector type | 2 RJ-45 female |
| Ethernet data rate | 10/100/1000 base-T, half/full duplex (auto detect) |
| Termination | Auto-MDIX, TIA/EIA T568B |
| Ethernet standards | 1 GbE (802.3ab) |
| Power over Ethernet (PoE) | Complies with IEEE 802.3af (PoE) |
| Protocols | |
| All supported | IPv4, TCP, UDP, DHCP, HTTPS, PTPv2, IGMPv2/v3, SSH |
| Security | AES-256, 802.1X, Active Directory authentication |
| Termination standard | TIA/EIA T 568B |
| Signal transmission distance | 330' (100 m) using CAT 5e/6/6a/7 cables |
| PoE transmission distance | 330' (100 m) using CAT 5e/6/6a/7 cables |
|
| Communications - external devices |
|---|
| USB configuration port | |
| Quantity/type | 1 front panel USB mini-B |
| Standard | Ethernet over USB |
|
| General |
|---|
| Power supply | External
Input: 100-240 VAC, 50-60 Hz
Output: 12 VDC, 1.5 A, 18 watts |
| NOTE | The NAVigator can be powered either locally by an external power supply or remotely using an optional power inserter. |
|
| Power consumption | |
| Device | 2.9 watts |
| Device and power supply | 3.6 watts |
| PoE | 4.5 watts |
| PoE | Complies with IEEE 802.3af (PoE), class 3 |
| Ambient temperature/humidity | Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 85%, noncondensing |
| Cooling | Convection, no vents |
| Thermal dissipation | |
| Device | 10.1 BTU/hr |
| Device and power supply | 12.3 BTU/hr |
| Device and power over ethernet | 21.1 BTU/hr |
| Mounting | |
| Rack mount | Yes, with optional rack shelf |
| Furniture mount | Yes, with optional under desk mounting kit |
| Enclosure type | Metal |
| Enclosure | 1.00" H x 8.75" W x 6.00" D (half rack wide)
(25 mm H x 222 mm W x 152 mm D)
(Depth includes connectors) |
| Product weight | 1.4 lbs (0.7 kg) |
| Regulatory compliance | CE, c-UL UL,C-tick, FCC Class A, ICES, KC, VCCI,
Complies with the appropriate requirements of RoHS, WEEE |
| Product warranty | 3 years parts and labor |
| Everlast power supply warranty | 7 years parts and labor |
| NOTE | All nominal levels are at ±10%. |
|
| NOTE | Specifications are subject to change without notice. |
|
| (5475-D5) |
