| IPL T PCS4i |
|
| Ethernet control interface |
|---|
| Connectors | 1 female RJ-45 female connector |
| Data rate | 10/100Base-T, half/full duplex with autodetect |
| Protocols | ARP, ICMP (ping), IP, TCP, UDP, DHCP, HTTP, SMTP, Telnet |
| Default settings | Link speed and duplex level = autodetected
IP address = 192.168.254.254
Subnet mask = 255.255.0.0
Gateway = 0.0.0.0
DHCP = off |
| Web server | Up to 200 simultaneous sessions
960 kB nonvolatile user memory |
| Program control | Extron Simple Instruction Set (SIS™) |
|
| AC control interface |
|---|
| Connectors | 4 IEC power connectors |
| Voltage | 120/240 VAC, 50-60 Hz |
| Minimum AC load | 20 mA, 2.4/4.4 watts at 120/240 VAC |
| Maximum AC load, aggregate | 10 A, 1200/2200 watts at 120/240 VAC |
| Maximum AC load, individual | 10 A, 1200/2200 watts at 120/240 VAC |
| Current sense | |
| Range | 5 mA to 10 A |
| Resolution | 0.1 mA steps from 5 mA to 99.9 mA
1 mA steps from 100 mA to 999 mA
10 mA steps from 1 A to 10 A |
| Tolerance | ±20% |
|
| Alarm relay control |
|---|
| Quantity/type | 1 normally open relay |
| Connector | (1) 3.5 mm captive screw connector, 2 pole |
| Contact rating | 24 V, 1 A |
|
| General |
|---|
| Power input | Internal
120/240 VAC, 50-60 Hz
15 watts |
| Temperature/humidity | Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing |
| Cooling | Convection, no vents |
| Mounting | |
| Rack mount | Yes, with optional 1U rack shelf |
| Furniture mount | Yes, under-furniture mountable with optional mounting kit |
| Enclosure type | Metal |
| Enclosure dimensions | 1.7" H x 8.7" W x 9.5" D (1U high, half rack wide)
(43 mm H x 220 mm W x 241 mm D)
(Depth excludes connectors.) |
| Product weight | 2.6 lbs (1.2 kg) |
| Regulatory compliance | CE, C-tick, FCC Class A, ICES, VCCI |
| Product warranty | 3 years parts and labor |
| Everlast power supply warranty | 7 years parts and labor |
| NOTE | All nominal levels are at ±10%. |
|
| NOTE | Specifications are subject to change without notice. |
|
| (6571-D11) |
