主要特性
-
Used to securely mount a TLP Pro 1025M, TLP Pro 725M, TLC Pro 1026M, TLC Pro 726M, TLS 1025M, or TLS 725M in a wall
-
Provides an elegant, aesthetically pleasing installation
-
Four locking arms provide secure installation in walls with thicknesses from 1/2 inch to 1 inch
-
Downloadable paper cutout template for easy installation
-
Touchpanel can be removed for maintenance
-
Allows integration and installation of a junction box for conduit runs
| 型号 |
产品说明 |
产品编号 |
| RWM 2 |
TLP, TLS Recessed Wall Mount Kit |
70-1141-23 |
The Extron RWM 2 is a recessed wall mount kit for 7 inch and 10 inch TouchLink Pro touchpanels, TouchLink Control Systems, and TouchLink Scheduling panels that allows them to be installed securely within a wall. When mounted into an RWM 2, the touchpanel surface lies slightly above the surrounding area. This allows the side LEDs to be visible for easy occupancy verification, while creating an elegant, aesthetically-pleasing installation.
特性
-
Used to securely mount a TLP Pro 1025M, TLP Pro 725M, TLC Pro 1026M, TLC Pro 726M, TLS 1025M, or TLS 725M in a wall
-
Provides an elegant, aesthetically pleasing installation
-
Four locking arms provide secure installation in walls with thicknesses from 1/2 inch to 1 inch
-
Downloadable paper cutout template for easy installation
-
Touchpanel can be removed for maintenance
-
Use the RWM 2 in drywall or furniture openings previously cut for TLP 350MV, TLP Pro 320M, TLP Pro 520M, or TLC Pro 521M
— Wall openings will need to be enlarged to accept the RWM 2.
-
Allows integration and installation of a junction box for conduit runs
|
相似产品
|
| |
Angle Mount Kits |
For TouchLink Pro Touchpanels, TLC Pro Series, and TouchLink Scheduling Panels |
| |
MMK 1 |
TLS 525M 门框安装套件 |
| |
MMK 2 |
TLS 725M 门框安装套件 |
| |
MMK 3 |
TLS 1025M 门框安装套件 |
| |
OCS 100 |
占用感应器 |
| |
RWM 1 |
Recessed Wall Mount Kit for TLP Pro 525M, TLC Pro 526M, and TLS 525M |
| |
SMB 111T |
用于 TLP Pro 300M 和 TLS 300M 的表面安装盒 |
| |
SMK 1 |
Surface Mount Kit for TLP Pro 525M and TLS 525M |
| |
SMK 2 |
Surface Mount Kit for TLP Pro 725M and TLS 725M |
| |
SMK 3 |
Surface Mount Kit for TLP Pro 1025M and TLS 1025M |
| |
TSP 系列 |
TouchLink 屏幕保护膜 |
技术参数
-
| RWM 2 |
|
| General |
|---|
| Mounting | Mounts into walls
Wall thickness range 0.50" to 1.00" |
| Enclosure material | Metal, painted white |
| |  |
| Enclosure dimensions | 4.72" H x 6.77" W x 2.59" D
(120 mm H x 172 mm W x 66 mm D) |
| Surface cutout dimensions | 4.42" H x 6.375" W
(112 mm H x 162 mm W) |
| Product weight | 0.68 lbs (0.31 kg) |
| Regulatory compliance | CE, RoHS, WEEE |
| Product warranty | 3 years parts and labor |
| NOTE | Specifications are subject to change without notice. |
|
| (4304-D2) |
| 装运尺寸和重量 |
| 产品编号 |
高度 |
宽度 |
深度 |
重量 |
| 70-1141-23 |
11.4 cm |
18.4 cm |
15.9 cm |
0.45 kg |
面板图
