HC 402 - Meeting Space Collaboration System, Decorator Tx, White
- Provide a transmitter/receiver set for audio/video switching and extension over shielded CATx cable
- HCT 101 D Transmitter – White one-gang decorator-style wallplate transmitter for HDMI, plus signal extension over shielded CATx cable
- Video Input Requirements
- Provide one HDMI video input connection
- Supported HDMI specifications include 1080p/60, data rates up to 6.75 Gbps, and HD lossless audio formats
- Support computer and video resolutions up to 1920x1200, including 1080p/60 and 2K
- Video Output Requirements
- Provide one RJ-45 jack for connection to matching HCR 102 receiver
- Support video resolutions up to 1920x1200, including 1080p/60 and 2048x1080p/60
- Support video transmission over shielded CATx cable up to 230 feet (70 meters)
- EDID Requirements
- Provide automatic EDID management between connected devices including HDMI output at HCR 102 receiver
- Provide a set of pre-stored EDID files
- Support capture of EDID from any connected display
- Support user uploading of custom-generated EDID files
- Support assignment of any pre-stored, captured, or custom uploaded EDID file to any input connection
- Provide automatic EDID management between connected devices including HDMI output at HCR 102 receiver
- HDCP Requirements
- The unit shall be HDCP compliant
- Audio Requirements
- Provide audio input connections
- One HDMI, embedded
- One 3.5 mm stereo mini jack, unbalanced analog stereo
- Support multiple embedded audio formats
- Support audio transmission over shielded CATx up to 230 feet (70 meters)
- Shall digitize analog stereo audio input for transmission over shielded CATx
- Provide audio input connections
- General Requirements
- Provide real-time verification of signal flow and operation
- Directly readable on RJ-45 signal and link LEDs
- Shall be compatible with CATx shielded twisted pair cable, and Extron XTP DTP 24 shielded twisted pair cable
- Support being locally or remotely powered
- Enclosure shall support installation into standard US one-gang electrical junction boxes
- Provide real-time verification of signal flow and operation
- Video Input Requirements
- HCR 102 Receiver - rack-mountable receiver for the extension of HDMI, audio, and control
- Video input requirements
- Provide video input connections
- One HDMI input
- One RJ-45 jack for connection to matching HCT 101 D transmitter
- Supported HDMI specifications include 1080p/60, data rates up to 6.75 Gbps, and HD lossless audio formats
- Provide video input connections
- Video output requirements
- provide one HDMI output for digital video signals with or without embedded audio
- Supported HDMI specifications include 1080p/60, data rates up to 6.75 Gbps, and HD lossless audio formats
- provide one HDMI output for digital video signals with or without embedded audio
- Audio output requirements
- Shall support embedded digital audio on HDMI output
- Shall provide a dedicated analog audio output connection
- One five-pole captive screw connector for selectable de-embedded or pass-through analog audio
- Transmission requirements
- Shall provide signal transmission distance capability of 230 feet (70 meters) for all supported video resolutions using a shielded CATx cable
- Video scaling requirements
- Shall provide a range of selectable video output rates from 640x480 to 1920x1200, including HDTV 1080p/60 and 2048x1080p/60
- Shall provide image scaling and video format conversion at 30-bit precision and support 1080i deinterlacing
- Shall provide aspect ratio control
- When in FILL mode, the video image on the output screen shall always fill the output screen without letterbox or pillarbox
- When in FOLLOW mode, the video image on the output screen shall always preserve the aspect ratio of the input signals without distortion
- Provide internal test patterns for calibration and setup
- Support automatic muting of video and sync output when no video input signal is present
- Shall support RGB and YCbCr digital video formats
- Shall provide automatic 3:2 and 2:2 pulldown detection
- HDCP Requirements
- The unit shall be HDCP compliant
- Shall provide the option to disable HDCP processing at HDMI input when passing unencrypted content
- Audio requirements
- Shall provide analog stereo audio de-embedding
- Shall support multiple embedded audio formats
- Shall support embedded HD lossless audio formats
- Shall provide selectable analog audio
- Stereo output
- Dual mono output of summed left and right channels using an Extron SIS™ command
- Control processing requirements
- Shall provide AV system control connections
- One 10/100 Ethernet port on RJ-45 connector
- One RS-232 port on 3-pole captive screw
- One IR port on 2-pole captive screw
- Four digital input/output ports on 5-pole captive screw
- Shall support the following protocols: ICMP (ping), IPv4, TCP, UDP, DHCP, DNS, HTTP, HTTPS, NTP, SFTP, SMTP, SNMP, SSH
- Shall support a Web-based AV resource management application that provides a means to manage, monitor, and control AV equipment
- Shall support control system synchronization to allow users to retain and recover configured endpoints in case of network or power failure
- Shall be configured using Extron Global Configurator® Plus or Extron Global Configurator Professional with support for the following:
- Provide remote monitoring and control via Ethernet
- Provide the ability to create E-mail notifications
- Provide multiple levels of password protection
- Provide the ability to create schedules and monitors
- Support Ethernet-controllable AV devices
- Support local variables and conditional logic
- Support triggering of standard CEC commands at HDMI output
- Shall provide AV system control connections
- Power requirements
- Shall accept local power
- Shall provide remote power to transmitter when connected to Extron external power supply
- General requirements
- Shall include a USB configuration port on the front panel for data access and firmware updates
- Shall be compatible with CATx shielded twisted pair cable, and Extron XTP DTP 24 shielded twisted pair cable
- Shall have a 1-inch (2.5 cm) high, half rack width metal enclosure
- Shall provide real-time verification of signal flow and operation
- Directly readable on RJ-45 signal and link LEDs
- Shall provide visual indication for signal presence, power, and link status on front panel
- Shall support Extron Product Configuration Software – PCS for setup and configuration
- Shall include an external, universal AC power supply capable of supporting 100 – 240 VAC, 50/60 Hz power
- Shall include Extron LockIt® HDMI cable lacing brackets
- Shall support the use of HDMI to DVI-D cables or adapters for DVI-D signals
- Video input requirements
- Shall meet regulatory compliances
- CE, c-UL, UL
- CE, C-tick, FCC Class A, ICES, VCCI
- Appropriate requirements of RoHS and WEEE
- Shall provide at least three (3) years parts and labor warranty
- Approved device shall be the Extron HC 402 (part number 42-285-01); no alternates or equals
- HCT 101 D Transmitter – White one-gang decorator-style wallplate transmitter for HDMI, plus signal extension over shielded CATx cable
